220V AC 24V Hybrid Solar Inverter 3300W 80A Mppt Hybrid Solar Inverter

Product Categories
Damien New Energy Technology (Shenzhen) Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

220V AC 24V Hybrid Solar Inverter 3300W 80A Mppt Hybrid Solar Inverter

Place of Origin : Guangdong, China

Brand Name : ENIKOL

Model Number : HF2430S80-H

Packaging Details : Colorful box

MOQ : 10 sets

Price : $470.00/sets 10-49 sets

Input Voltage : (170Vac~280Vac) ±2%;(90Vac-280Vac)±2%

Output Voltage : 230Vac

Output Current : 30A

Output Frequency : 50Hz ± 0.3Hz/60Hz ± 0.3Hz

Output Type : Single

Size : 378mm*280mm*103mm

Type : MPPT

Inverter Efficiency : 95%

Certificate : CE(EN62109-1)

Warranty : 1-3 Years

Weight : 6.9KG

Communication Mode : TTL serial communication

Working Temperature : -35℃ ~ +45℃

MPPT Tracking Efficiency : >99%

Work Time (h) : 24H

Maximum PV open circuit voltage : 500Vdc

PV operating voltage range : 120-500Vdc

Battery voltage range : 20-33Vdc

Maximum input power : 4000W

PV charging current range (can be set) : 0-80A

Port : shenzhen

Contact Now

220vac Hybrid Solar Inverter 3300w 24v + 80A Mppt Solar Charger + Battery Charger Mppt Hybrid Solar Inverter

Product Description
the series is a new all-in-one hybrid solar inverter charger, which integrates PV charge &Grid charge with sine wave output,For home,outdoor, RV, etc., off-grid hybrid inverter controller..
220V AC 24V Hybrid Solar Inverter 3300W 80A Mppt Hybrid Solar Inverter
220V AC 24V Hybrid Solar Inverter 3300W 80A Mppt Hybrid Solar Inverter
220V AC 24V Hybrid Solar Inverter 3300W 80A Mppt Hybrid Solar Inverter
220V AC 24V Hybrid Solar Inverter 3300W 80A Mppt Hybrid Solar Inverter
220V AC 24V Hybrid Solar Inverter 3300W 80A Mppt Hybrid Solar Inverter
220V AC 24V Hybrid Solar Inverter 3300W 80A Mppt Hybrid Solar Inverter
220V AC 24V Hybrid Solar Inverter 3300W 80A Mppt Hybrid Solar Inverter
220V AC 24V Hybrid Solar Inverter 3300W 80A Mppt Hybrid Solar Inverter
220V AC 24V Hybrid Solar Inverter 3300W 80A Mppt Hybrid Solar Inverter
Specification
Place of Origin
Shenzhen,China
Output Voltage
220V/230v
Phase
Single phase(standalone)
Output Frequency
50Hz/ 60Hz
Size
378*280*103mm
Inverter Efficiency
>95%
Warranty
36 months
Output voltage waveform
Pure sine wave
Certificate
CE(IEC/EN62109-1,-2),ROHS2.0
Rated power
3300w
Color
White
AC charge current
60A
PV charge current
80A
Wifi function
support
Maximum PV open circuit voltage
100vdc
Battery type
Lead acid or lithium battery
6.2Weight
6.9kg
